Total TWPS101 Automatic pump control 10A
KSh 3,999.00
Key Features
-
Dry-Run Protection: Cuts power to the pump automatically if no water enters the suction line, preventing motor burnout and impeller melt.
-
Auto-Start & Stop: Activates the pump when pressure drops below 1.5 bar (tap turned on) and stops it when flow drops below ~2 L/min (tap turned off).
-
LED Control Panel: Displays clear status lights for Power On, Pump On, and Failure, along with a Restart/Reset button.
-
Internal Check Valve: Built-in non-return valve prevents water hammer and maintains system prime.
TOTAL TWPS101 is an electronic pressure switch and flow controller designed to automate water pumps up to 1100W (1.5 HP). It turns the pump on when a downstream tap is opened and shuts it off when the flow stops, maintaining constant line pressure without needing an expansion tank.
Technical Specifications
| Feature / Metric | Specification |
| Model | TWPS101 |
| Input Voltage | 220–240 V ~ 50/60 Hz |
| Max. Current | 10 A |
| Max. Motor Power | 1100 W (1.5 HP) |
| Starting / Cut-In Pressure | 1.5 bar (22 psi) |
| Max. Working Pressure | 10 bar (145 psi) |
| Inlet / Outlet Size | 1″ Male × 1″ Male (G1) |
| Protection Degree | IP65 |
| Max. Liquid Temperature | 60°C |
| Weight | 2 kg |
|---|
