Total TMT5110004 Digital multimeter 1000V 9999Counts
KSh 7,999.00
Digital multimeter
VA colour display screen
Display: TRUR RMS 9999 counts
DC/AC
Current:9.999mA/99.99mA/600mA/10A
DC
Voltage:99.99mV/999.9mV/9.999V/99.9
V/1000V
AC
Voltage:99.99mV/999.9mV/9.999V/99.9
V/750V
Resistance:999.9Ω/9.999kΩ/99.99kΩ/99
9.9kΩ/9.999MΩ/99.99MΩ
Capacitance:9.999nF/99.99nF/9.999nF/9
TOTAL TMT5110004 is a high-end Smart True RMS digital multimeter with a 9999-count color screen display, designed for advanced electrical diagnostics, industrial maintenance, and electronics servicing.
| Technical Specification | Detail |
| Model | TMT5110004 |
| Display Resolution | 9999 Counts True RMS Color VA LCD Display |
| DC Voltage Range | 9.999mV / 99.99mV / 999.9mV / 9.999V / 99.99V / 999.9V (±0.5%) |
| AC Voltage Range | 9.999mV / 99.99mV / 999.9mV / 9.999V / 99.99V / 750V (±0.8%) |
| DC / AC Current | 9.999mA / 99.99mA / 999.9mA / 9.999A (±1.0%) |
| Resistance Range | 999.9Ω / 9.999kΩ / 99.99kΩ / 999.9kΩ / 9.999MΩ / 99.99MΩ |
| Capacitance Range | 9.999nF / 99.99nF / 999.9nF / 9.999μF / 99.99μF / 999.9μF / 9.999mF / 99.99mF |
| Frequency Range | 9.999Hz / 99.99Hz / 999.9Hz / 9.999kHz / 99.99kHz / 999.9kHz / 9.999MHz |
| Temperature Range | -40°C to 1000°C (-40°F to 1832°F) |
| Safety Rating | CAT III 1000V / CAT IV 600V |
| Power Supply | Built-in rechargeable Lithium battery / 2 x AAA batteries |
| Packaging | Color box with protective carrying pouch, thermocouple probe, and test leads |
Key Features:
-
9999-Count High Precision Screen: High-contrast color display provides clear readings for fine-voltage drift and low-current electronic testing.
-
Smart Auto & Manual Dual Mode: Automatically identifies voltage, resistance, and continuity, while allowing manual mode toggles for precise diagnostic control.
-
True RMS Measurement: Delivers reliable AC readings on irregular or distorted non-sinusoidal waveforms created by variable speed drives and inverter systems.
-
Non-Contact Voltage (NCV) & Live Test: Built-in NCV sensor detects live AC voltage lines through insulation without direct metal exposure.
| Weight | 2 kg |
|---|
